JH6000A-4 Decomposition product detector
?
recommendation index：
Detection components, high accuracy, good stability
Portable design, fast testing, low air consumption, environmentally friendly
Automatic flow control, efficient and accurate, effectively reducing sample gas emissions
Expert systems provide intelligent diagnostics
Detection of the main products of cracking of insulating materials inside SF6 electrical equipment: SO2, SOF2, H2S, CO, HF
name | component | parameter |
minimum detectable quantity | SO2+SOF2、H2S、HF | ≤0.1μL/L |
CO
| ≤0.5μL/L | |
precision | SO2+SOF2、H2S、HF | measurement value ≤ 10 μL/L, error ≤ ± 0.5 μL/L measured value > 10 μL/L, error≤ ± 5%. |
CO | measurement value ≤ 50 μL/L, error≤ ± 2.0 μL/L measurement value > 50 μL/L, error ≤ ± 4% | |
repeatability | SO2+SOF2 、H2S、HF | measured value ≤ 10 μL/L, ≤ 0.2 μL/L measured value > 10 μL/L, ≤ 2% |
CO | measured value ≤ 50 μL/L, ≤ 1.5 μL/L measured values > 50 μL/L~ 1000 μL/L, ≤ 3% | |
range | SO2+SOF2 | 0～100μL/L,0～2000μL/L |
H2S | 0～100μL/L | |
HF | 0～20μL/L | |
CO | 0～1000μL/L |
Related recommendations
JHLK100-HQ series High Precision Portable Mixed Gas Leak Detector
